RDR75
Integrated Blocks with tie bar
For uniform wear throughout the tyre tread life.
Intricate sipe design
Improves tread block stiffness and grip.
Wider open shoulder
Reduces turning side forces and improves heat dissipation.
Balanced Rib Ratio
Provides higher mileage and even wear.
Advance polymers and reinforcing agents
Are used to maximize the tire life in adverse operating conditions.
Compare tire conditions across usage percentages to identify subtle wear patterns
before they turn into risks.
25%
50%
75%
| Tire Size | PR/LR | LI / SI | TREAD DEPTH (MM) | RIM SIZE (INCH) | MAX. OVERALL DIA (MM) | MAX. OVERALL WIDTH (MM) | SINGLE MAX LOAD (KG@KPA) | DUAL MAX LOAD (KG@KPA) |
|
|
|
|
|
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| *205/75R17.5 | 16H | 124/122M | 13.0 | 6.00 | 755 | 205 | 1600@720 | 1500@720 | Y | - | - | - | Y | Y |
| 215/75R17.5 | 16H | 128/126M | 12.5 | 6.00 | 768 | 213 | 1800@760 | 1700@760 | Y | D | B | 73dB | Y | Y |
| 235/75R17.5 | 16H | 132/130M | 13.0 | 6.75 | 797 | 237 | 2000@775 | 1900@775 | Y | D | B | 73dB | Y | Y |
| 245/70R17.5 | 18J | 136/134M | 13.0 | 7.50 | 789 | 248 | 2240@775 | 2120@775 | Y | D | B | 73dB | Y | Y |
| 265/70R19.5 | 16H | 140/138M | 14.5 | 7.50 | 870 | 265 | 2500@800 | 2360@800 | Y | D | B | 73dB | Y | Y |
| 265/70R19.5 | 18J | 140/138M | 14.5 | 7.50 | 870 | 265 | 2500@800 | 2360@800 | Y | D | B | 73dB | Y | Y |
| 285/70R19.5 | 16H | 146/145L | 16.0 | 8.25 | 900 | 285 | 3000@850 | 2900@850 | Y | D | B | 73dB | Y | Y |
| 285/70R19.5 | 18J | 146/144M | 16.0 | 8.25 | 900 | 285 | 3000@850 | 2800@850 | Y | D | B | 73dB | Y | Y |
| Tire Size | PR/LR | LI / SI | TREAD DEPTH (32NDS) | RIM SIZE (INCH) | MAX. OVERALL DIA (MM) | MAX. OVERALL WIDTH (MM) | SINGLE MAX LOAD (LBS/PSI) | DUAL MAX LOAD (LBS/PSI) |
|---|---|---|---|---|---|---|---|---|
| 215/75R17.5 | 16H | 128/126M | 15.7 | 6.00 | 768 | 213 | 3970/110 | 3750/110 |
| 235/75R17.5 | 16H | 132/130M | 16.4 | 6.75 | 797 | 237 | 4410/112 | 4190/112 |
| 245/70R17.5 | 16H | 134/132M | 16.4 | 7.50 | 789 | 248 | 4675/112 | 4410/112 |
