RDC66

Construction Drive Open Shouder Mix Service

RDC66

Construction Drive Open Shouder Mix Service

RDC66 delivers superior grip, long service life, and enhanced casing protection for construction, mining, and off-road operations as a heavy-duty drive-axle radial truck tire built for demanding terrain.

Enquire Now

Warranty & Benefits

Features

Every Ralson tire is built for consistent traction and smooth handling, engineered to perform reliably under pressure across every journey and terrain.

Larger tread blocks Provide strong grip and improved load capacity.

Extra-deep tread design Delivers extended service life and higher mileage.

All-terrain open shoulder blocks Provide grip and self-cleaning, even in rough conditions.

Wider contact area Delivers smoother ride and better flotation.

Solid centre rib Improves resistance to cuts and mechanical wear for longer life.

Advance polymers and reinforcing agents Are used to maximize the tire life in adverse operating conditions.

Wear Isn’t Always Visible. Until It Is.

Compare tire conditions across usage percentages to identify subtle wear patterns
before they turn into risks.

01

25%

02

50%

03

75%

Specifications

Our tires are available in a wide range of sizes with precise load, speed
and tread depth ratings for every fleet need.

Tire Size	PR/LR	LI / SI	TREAD DEPTH (MM)	RIM SIZE (INCH)	MAX. OVERALL DIA (MM)	MAX. OVERALL WIDTH (MM)	SINGLE MAX LOAD (KG@KPA)	DUAL MAX LOAD (KG@KPA)
315/80R22.5	20L	158/156K	20.2	9.00	1089	321	4250@900	4000@900	Y	C	B	73dB	Y	Y
11R22.5	18J	148/145L	24.0	8.25	1070	292	3150@830	2900@830	N	-	-	-	Y	N

North America

Tire Size	PR/LR	LI / SI	TREAD DEPTH (32NDS)	RIM SIZE (INCH)	MAX. OVERALL DIA (MM)	MAX. OVERALL WIDTH (MM)	SINGLE MAX LOAD (LBS/PSI)	DUAL MAX LOAD (LBS/PSI)
11R22.5	16H	146/143M	30.2	8.25	1070	292	6610/120	6005/120
315/80R22.5	20L	161/157K	25.4	9.00	1089	319	10200/130	9090/130

Certifications & Markings

Our tires are available in a wide range of sizes with precise load, speed,
and tread depth ratings for every fleet need.

Similar Products

RAC52

RAC52 delivers reliable grip, effective thermal control, and longer tread life as a durable all-position radial truck tire for on-road and off-road cargo and construction operations across mixed-service routes.

RAC55

RAC55 delivers strong grip, best-in-class mileage, and long casing life as a durable all-position radial truck tire for waste haul, regional, and mixed-service operations.

RAC82

RAC82 delivers consistent performance and long casing life in heavy waste-haul operations, using a reinforced block design, cooling-focused siping, and self-cleaning grooves to handle constant scrubbing, stop-start cycles, and harsh debris.

RDC56

RDC56 delivers long life, superior grip, and improved retreadability for construction, mining, and mixed-service fleets, using bigger tread blocks, deep grooves, and a robust casing in a heavy-duty drive-axle design.

RAC88

RAC88 delivers stable, reliable performance in demanding construction and mixed-service operations, combining a reinforced tread, wide blocks and grooves, and an advanced compound to ensure strong grip, even wear, and higher mileage across varied terrains.

RDC88

RDC88 delivers strong traction and durability in demanding construction operations, using reinforced shoulders, zig-zag grooves, and a heavy-duty construction to maintain stability, heat control, and consistent performance on rough roads.
