Integrated blocks and optical sipes
Ensure even wear and durability.
Optical Sipes with Cooling Fins
Helps initial traction and dissipates heat.
Closed shoulder
Design manages load and torque effectively.
Balanced Rib Ratio
Ensures even pressure distribution.
Optimized groove angles
Enable self-cleaning and easy stone ejection, reducing downtime.
Lateral groove edge bits
Enhance road grip.
Shoulder window design
Promotes thermal control and traction.
Advance polymers and reinforcing agents
Are used to maximise the tire life in adverse operating conditions.
Compare tire conditions across usage percentages to identify subtle wear patterns
before they turn into risks.
25%
50%
75%
| Tire Size | PR/LR | LI / SI | TREAD DEPTH (MM) | RIM SIZE (INCH) | MAX. OVERALL DIA (MM) | MAX. OVERALL WIDTH (MM) | SINGLE MAX LOAD (KG@KPA) | DUAL MAX LOAD (KG@KPA) |
|
|
|
|
|
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 325/95R24 | 22M | 162/160K | 16.2 | 9.00 | 1232 | 321 | 4750@850 | 4500@850 | Y | - | - | - | Y | N |
| 12.00R24 | 20L | 160/156K | 16.2 | 8.50 | 1230 | 317 | 4500@850 | 4000@850 | Y | C | B | 73dB | Y | N |
| 12.00R24 | 22M | 162/160K | 16.2 | 8.50 | 1230 | 317 | 4750@850 | 4500@850 | Y | C | B | 73dB | Y | N |
