Features

Every Ralson tire is built for consistent traction and smooth handling, engineered to perform reliably under pressure across every journey and terrain.

Shoulder window Design promotes traction and thermal control.

Tie-bar blocks with notches Promote uniform wear and extended tread life.

Open shoulder pattern Provides powerful traction with self-cleaning capability.

Angled grooves with stone ejectors Improve stone ejection and reduce downtime.

Elliptical–optical sipe design Delivers consistent traction over tread life.

Specifications

Our tires are available in a wide range of sizes with precise load, speed
and tread depth ratings for every fleet need.

Tire Size	PR/LR	LI / SI	TREAD DEPTH (MM)	RIM SIZE (INCH)	MAX. OVERALL DIA (MM)	MAX. OVERALL WIDTH (MM)	SINGLE MAX LOAD (KG@KPA)	DUAL MAX LOAD (KG@KPA)
*11.00R20	16H	150/147K	-	8.00	-	-	3350@830	3075@830	N	-	-	-	Y	N
*12.00R20	18J	154/151K	18.9	8.50	1132	325	3750@830	3450@830	N	-	-	-	Y	N
255/70R22.5	16H	140/137L	17.4	7.50	939	258	2500@830	2300@830	Y	D	B	73dB	Y	N
295/80R22.5	18J	152/148K	19.0	9.00	1060	310	3550@850	3150@850	Y	D	B	73dB	Y	Y
315/80R22.5	20L	161/157K	19.1	9.00	1087	323	4625@900	4125@900	Y	D	B	73dB	Y	Y
385/65R22.5	20L	164K	19.0	11.75	1083	388	5000@900	-	Y	D	B	73dB	Y	Y
425/65R22.5	20L	165K	18.8	12.25	1138	422	5150@830	-	Y	D	B	73dB	Y	Y
11R22.5	18J	148/145L	19.1	8.25	1061	292	3150@830	2900@830	N	-	-	-	Y	N
13R22.5	18J	156/150K	18.9	9.75	1132	325	4000@860	3350@860	Y	D	B	73dB	Y	Y

North America

Tire Size	PR/LR	LI / SI	TREAD DEPTH (32NDS)	RIM SIZE (INCH)	MAX. OVERALL DIA (MM)	MAX. OVERALL WIDTH (MM)	SINGLE MAX LOAD (LBS/PSI)	DUAL MAX LOAD (LBS/PSI)
255/70R22.5	16H	140/137L	21.9	7.50	939	260	5510/120	5070/120
315/80R22.5	20L	161/157K	24.1	9.00	1087	323	10200/130	9090/130
385/65R22.5	20L	164K	23.9	11.75	1083	388	11000/130	-
425/65R22.5	20L	165K	23.7	12.25	1138	422	11400/120	-
11R22.5	16H	146/143K	24.1	8.25	1061	288	6610/120	6005/120
11R24.5	16H	149/146K	24.1	8.25	1112	288	7160/120	6610/120
